Line 12 (Sapphire)
Overview
StatusOperational
Owner Government of the State of São Paulo
LocaleGreater São Paulo, Brazil
Termini
Connecting lines
Stations13
Service
TypeCommuter rail
SystemSão Paulo Metropolitan Trains
Operator(s) Companhia Paulista de Trens Metropolitanos
Depot(s)Brás rail yard
Manoel Feio rail yard
Rolling stock
History
Opened1 April 1934 (1934-04-01)[lower-alpha 1]
Technical
Line length39 km (24 mi)
Track gauge1,600 mm (5 ft 3 in)[1]
Electrification3,000 V DC catenary
Operating speed60 km/h (37 mph)
SignallingAutomatic block signaling
Route map
to Jundiaí
to Luz
Brás
to Rio Grande da Serra
Viaduto Bresser
Av. Salim Farah Maluf
 Tatuapé
Viaduto Carlos Ferraci
 Engenheiro Sebastião Gualberto
opened c. 1886
closed 2000
to Estudantes
 Agente Cícero
opened 1951
closed c. 1975
 Gabriela Mistra
Engenheiro Trindade
opened 1934
closed 1999
 Cangaíba
 Engenheiro Goulart
to Aeroporto-Guarulhos
 USP Leste
 Comendador Ermelino
Cement industry
Estrada de Cumbica
 União de Vila Nova
Viaduto da Jacu Pêssego
 São Miguel Paulista
R. Arlindo Colaço
Itaquera River
 Jardim Helena-Vila Mara
Lageado Brook
 Itaim Paulista
 Jardim Romano
Industrial track
Industrial track
Manoel Feio rail yard
 Engenheiro Manoel Feio
MRS Logística
to São José dos Campos
Cargo termini
 Itaquaquecetuba
 Aracaré
Brasil estado 066 jct.svg
SP-66
Rodovia São Paulo-Mogi
to Luz
Calmon Viana
Down arrow Construction suspended
Rodoanel Mário Covas
 Suzano
to Estudantes

Line 12 (Sapphire) (Portuguese: Linha 12–Safira, formerly Line F (Purple), is one of the seven lines operated by CPTM and one of the thirteen lines that make up the Sao Paulo Metro Rail Transport Network, in Brazil.[2]

Stations

Code Station Platforms Position Connections City
LUZ Luz Island and side platforms At-grade
São Paulo BAS Brás Island and side platforms At-grade
São Paulo
TAT Tatuapé Island platforms At-grade

Tatuapé Bus Terminal		 São Paulo
EGO Engenheiro Goulart Island platforms At-grade São Paulo
USL USP Leste Island platform At-grade - São Paulo
ERM Comendador Ermelino Island platform At-grade - São Paulo
SMP São Miguel Paulista Island platform At-grade - São Paulo
JHE Jardim Helena-Vila Mara Island platform At-grade - São Paulo
ITI Itaim Paulista Island platform At-grade - São Paulo
JRO Jardim Romano Island platform At-grade - São Paulo
EMF Engenheiro Manoel Feio Side platforms At-grade - Itaquaquecetuba
ITQ Itaquaquecetuba Island platform At-grade - Itaquaquecetuba
ARC Aracaré Island platform At-grade - Itaquaquecetuba
CMV Calmon Viana Island and side platforms At-grade Poá

Notes

References

  1. ↑ Ferreira, Robert; Tharcisiu Alves. (January 2012). "São Paulo Metro". www.nycsubway.org. www.nycsubway.org. Archived from the original on 2014-02-02. Retrieved 2014-02-02. On Lines 1, 2 and 3, the track gauge is a non standard 1600 mm, the third rail is 750 V DC and under running. For Lines 4 and 5, the track gauge is 1435 mm and they use overhead pantograph, precluding any connection to the rest of the system, plus the 4 and 5 lines can't connect because the trains on the 4 line use drive-less technology while trains on 5 line are OPTO. Lines 7, 8, 9, 10, 11 and 12 (operated by CPTM) are all 1600mm and use overhead pantograph.
  2. ↑ Line 12 (CPTM) Website (Portuguese) Archived 2011-07-22 at the Wayback Machine
